3G/GPRS specifications:
Quad-band 850MHz GSM, 900MHz EGSM, 1800MHz DCS, 1900MHz PCs - connect onto any global GSM network with any 2G SIM
This is the European and American Versions
Fully-integrated GPS (Qualcomm PM8015 GPS) that can be controlled and query over the same serial port
Make and receive voice calls using a headset or an external 8Ω speaker + electret microphone
Send and receive SMS messages
Send and receive GPRS data (TCP/IP, HTTP, etc.)
AT command interface can be used with 300, 600, 1200, 4800, 9600, 19200, 38400, 57600, 115200, 230K, 461K, 961K, 3.2M, 3.7M and 4.0Mbps
Native USB support - plug it into a computer and you'll get serial ports for AT commands, GPS NMEA as well as a modem (note we've only tried out the AT&NMEA ports on Windows)GPS specifications:
16 acquisition channels
GPS L1 C/A code
Sensitivity - Tracking: -157 dBm; Cold starts: -144 dBm
Time-To-First-Fix - Cold starts: 100s (typ.); Hot starts: 1s (typ.)
Accuracy: approx 2.5 meters| Name | Size | # Downloads |
|---|---|---|
| Scheme_SIM5320_shield.pdf | 186.22 kB | 444 |
| SIM5230.drl | 4.62 kB | 402 |
| SIM5230-B.Cu.gbr | 117.85 kB | 366 |
| SIM5230-B.Mask.gbr | 2.23 kB | 339 |
| SIM5230-B.SilkS.gbr | 1.67 kB | 346 |
| SIM5230-Edge.Cuts.gbr | 1023 B | 359 |
| SIM5230-F.Mask.gbr | 8.5 kB | 356 |
| SIM5230-F.Cu.gbr | 320.15 kB | 381 |
| SIM5230-F.SilkS.gbr | 47.11 kB | 349 |
